Gigabyte Nvidia GeForce RTX 2060 Super Gaming Windforce 8GB GDDR6 - A - Premium Edition
Gigabyte Nvidia GeForce RTX 2060 Super Gaming Windforce 8GB GDDR6 - A - Premium Edition
Product Description -
Summary - Good overall condition, unfortunately the box has been lost. Specifications can be seen below -
Graphics Processor
Graphics Card
- Release Date
- Jul 9th, 2019
- Generation
- GeForce 20
- Predecessor
- GeForce 10
- Successor
- GeForce 30
- Production
- Active
- Bus Interface
- PCIe 3.0 x16
Clock Speeds
- Base Clock
- 1470 MHz
- Boost Clock
-
1650 MHz
1815 MHz (+10%)
- Memory Clock
- 1750 MHz
14 Gbps effective
Memory
- Memory Size
- 8 GB
- Memory Type
- GDDR6
- Memory Bus
- 256 bit
- Bandwidth
- 448.0 GB/s
Render Config
- Shading Units
- 2176
- TMUs
- 136
- ROPs
- 64
- SM Count
- 34
- Tensor Cores
- 272
- RT Cores
- 34
- L1 Cache
- 64 KB (per SM)
- L2 Cache
- 4 MB
Theoretical Performance
- Pixel Rate
-
105.6 GPixel/s
116.2 GPixel/s
- Texture Rate
-
224.4 GTexel/s
246.8 GTexel/s
- FP16 (half)
-
14.36 TFLOPS
15.80 TFLOPS (2:1)
- FP32 (float)
-
7.181 TFLOPS
7.899 TFLOPS
- FP64 (double)
-
224.4 GFLOPS
246.8 GFLOPS (1:32)
Board Design
- Slot Width
- Dual-slot
- Length
-
229 mm
280 mm9 inches
11 inches
- Width
-
113 mm
116 mm4.4 inches
4.6 inches
- Height
-
35 mm
40 mm1.4 inches
1.6 inches
- TDP
- 175 W
- Suggested PSU
- 450 W
- Outputs
-
1x DVI
1x HDMI 2.0
2x DisplayPort 1.4a
1x USB Type-C
1x HDMI 2.0
3x DisplayPort 1.4a
1x USB Type-C
- Power Connectors
-
1x 8-pin
1x 6-pin + 1x 8-pin
- Board Number
- PG160 SKU 65
Graphics Features
- DirectX
- 12 Ultimate (12_2)
- OpenGL
- 4.6
- OpenCL
- 3.0
- Vulkan
- 1.3
- CUDA
- 7.5
- Shader Model
- 6.7
TU106 GPU Notes
| Ray Tracing Cores: 1st Gen Tensor Cores: 2nd Gen NVENC: 7th Gen NVDEC: 4th Gen PureVideo HD: VP10 VDPAU: Feature Set J |
This card has passed several tests. These tests include - A 1 hour run on Furmark (for temperature readings and to ensure stability), one run on each of Unigene’s Heaven and Superposition benchmarks (for performance figures in relation to brand new models) and we only buy cards in once they’ve passed all 3 tests and remained below 75°C, even under the extremely high loads of a 1 hour Furmark test. Finally, we perform a visual check to ensure it’s in good enough aesthetic condition before we buy the product in. This insures we never have stock we’re not happy with, so you never have to worry when buying from us!
All our cards are in good working condition as explained above. However, if you receive your order and it unfortunately doesn’t work, don’t panic, we have a 30 day return window, with money back guarantee. All so you can enjoy the bargain without being worried about any issues.
Full specifications can be found at the manufacturers website.
