Sapphire AMD Radeon RX 6700XT Pulse 12GB GDDR6 - A - Premium Edition
Sapphire AMD Radeon RX 6700XT Pulse 12GB GDDR6 - A - Premium Edition
Product Description -
Summary - Great condition and performing well too, without the original box unfortunately. Specifications below -
Graphics Processor
- GPU Name
- Navi 22
- GPU Variant
- Navi 22 XT
(215-127000006)
- Architecture
- RDNA 2.0
- Foundry
- TSMC
- Process Size
- 7 nm
- Transistors
- 17,200 million
- Density
- 51.3M / mm²
- Die Size
- 335 mm²
- Chip Package
- BGA-1701
Graphics Card
Clock Speeds
- Base Clock
- 2321 MHz
- Game Clock
- 2424 MHz
- Boost Clock
- 2581 MHz
- Memory Clock
- 2000 MHz
16 Gbps effective
Memory
- Memory Size
- 12 GB
- Memory Type
- GDDR6
- Memory Bus
- 192 bit
- Bandwidth
- 384.0 GB/s
Render Config
- Shading Units
- 2560
- TMUs
- 160
- ROPs
- 64
- Compute Units
- 40
- RT Cores
- 40
- L0 Cache
- 32 KB per WGP
- L1 Cache
- 128 KB per Array
- L2 Cache
- 3 MB
- L3 Cache
- 96 MB
Theoretical Performance
- Pixel Rate
- 165.2 GPixel/s
- Texture Rate
- 413.0 GTexel/s
- FP16 (half)
- 26.43 TFLOPS (2:1)
- FP32 (float)
- 13.21 TFLOPS
- FP64 (double)
- 825.9 GFLOPS (1:16)
Board Design
- Slot Width
- Dual-slot
- Length
-
267 mm
260 mm10.5 inches
10.2 inches
- Width
-
110 mm
120 mm4.3 inches
4.7 inches
- Height
-
40 mm
49 mm1.6 inches
1.9 inches
- TDP
- 230 W
- Suggested PSU
- 550 W
- Outputs
- 1x HDMI 2.1
3x DisplayPort 1.4a
- Power Connectors
- 1x 6-pin + 1x 8-pin
- Board Number
- 109-D512A7-00_02
Graphics Features
- DirectX
- 12 Ultimate (12_2)
- OpenGL
- 4.6
- OpenCL
- 2.1
- Vulkan
- 1.3
- Shader Model
- 6.7
Navi 22 GPU Notes
| Generation: Navi II Codename: Navy Flounder Ray Tracing Cores: 1st Gen Infinity Cache: 1st Gen Graphics/Compute: 10.3.2 Shader ISA: GFX10.3 (gfx1031) Display Core Next: 3.0.0 Video Core Next: 3.0.0 System DMA: 5.2.2 Platform Security Processor: 11.0.11 Per SIMD32: - 10 KB Scalar Register File Per CU: - 16 KB Vector Data Cache - 64 KB Local Data Share (GCN-Mode) Per WGP: - 16 KB Scalar Data Cache / K Cache - 32 KB Instruction Cache - 128 KB Local Data Share |
This card has passed several tests. These tests include - A 1 hour run on Furmark (for temperature readings and to ensure stability), one run on each of Unigene’s Heaven and Superposition benchmarks (for performance figures in relation to brand new models) and we only buy cards in once they’ve passed all 3 tests and remained below 75°C, even under the extremely high loads of a 1 hour Furmark test. Finally, we perform a visual check to ensure it’s in good enough aesthetic condition before we buy the product in. This insures we never have stock we’re not happy with, so you never have to worry when buying from us!
All our cards are in good working condition as explained above. However, if you receive your order and it unfortunately doesn’t work, don’t panic, we have a 30 day return window, with money back guarantee. All so you can enjoy the bargain without being worried about any issues.
Feel free to check out our reviews on Google and Trustpilot for added piece of mind :
